McHale R5 Round Bale Handler

The McHale R5 is ideal for transporting
bales, which have been tipped on their
ends in the field. It can also be used to
collect bales after wrapping and rotate
them through 90 degrees and stack
them on their ends, so that they hold
their shape better

R5 – Technical Information
Weight: 160 kg 352 lbs
Height: 0.59 m 2’0”
Length: (overall) 1.42 m 4’7”
Open Distance Centres of the Arms: between 1.65 m 5’5”
Close Distance between Centres of the Arms: 0.67 m (open) 2’3” (open)
Lifting Capacity: 1100 kg 2425 lbs
Minimum Hydraulic Pressure: 150 bar 2250 lbs/sq.in
Hydraulic Requirements: One Double Acting Service
